Getac T800



The rugged Getac T800 has built in functions in order to increase productivity of professional field work even in the harshest environments. The unit has a sharp 8.1"HD (1280x800) multi-touch with 600 nits LumiBond® 2.0 display with enhanced sunlight readable technology.

Getac T800 is equipped with the energy efficient Intel® Atom x7-Z8700 1.6GHz, up to 2.40 GHz - 2MB Cache. The memory is expandable up to 8GB, and storage up to 128GB. Getac´s LifeSupport™ hot-swap battery technology gives the field worker the opportunity to prolong the battery time through quick and easy battery swops into a second expanded battery (14.4V, 2100mAh)1).

Getac has designed the T800 to do the work in an efficient and reliable way. Getac T800 has integrated Bluetooth 4.0, HD camera and optional possibilities as Smartcard reader, GPS and 3G WWAN, 4G/LTE WWAN and much more. With optional SnapBack add-ons it is easy to customise and expand the unit into the optimal tool for the individual user.

Getac T800 meets the requirements of IP65 and MIL-STD-810G when it comes to challenges like water,
dust, shock, drop, vibration and a broad operating temperature range. (See more pictures by using the arrows in the right column)

1) Optional accessory




Specification:

CPU:
Intel® Atom x7-Z8700 1.6GHz,
burst up to 2.40 GHz- 2MB Cache
Memory: 4GB LPDDR3 expandable to 8GB
Storage: eMMC 64GB/128GB
OS: Windows 10 Professional
Display:
8.1" IPS TFT LCD HD
(1280 x 800)
600 nits LumiBond® 2.0 display,
with sunlight readable technology
I/O Interface:
USB 3.0 (9-pin)
Headphone out/Mic-in Combo,
DC in Jack, Micro HDMI,
Docking connector (24-pin)
Optional RF antenna pass-through
for GPS, WWAN and WLAN
Communication interface:
10/100/1000 base-T Ethernet
(occupies expansion slot)1) Intel® Dual Band Wireless-AC 7265, 802.11ac,
Bluetooth version 4.0, Dedicated GPS1),
4G LTE mobile broadband1)
Camera:
FHD webcam, 8MP auto focus rear camera.
Expansion Slots:
RS232, Micro SD or Ethernet,
1D/2D imager barcode reader,1)
Snapback Add-ons:
Smart Card and contactless
RFID/NFC reader combo1)
Second expanded battery1)
Smart card and Magnetic Stripe reader1)
Smart Card & UHF RFID reader1)
Battery:
Li-Ion battery (7.4V, 4200mAh)v
LifeSupport™ battery swappable
technology (only with SnapBack 2nd expanded battery)
Power:
AC adapter (65W, 100-240VAC, 50/60Hz)
Environmental:
MIL-STD-810G and IP65
certified, 6 feet drop resistant
Dimensions: 227 x 151 x 24 mm,
(9 x 6x 0.9 inches)
Weight: 880 grams2) (1.95 pounds)2)

1) Optionals. (Please observe that all Snapback Add-ons are mutually optionals)
2) No accessories mounted
